Hitachi Industrial Equipment Systems Land-Based Multistage Motor Pump Model JDM
Hitachi Industrial Equipment Systems
A compact horizontal direct-acting multi-stage motor pump that accommodates high lift with easy maintenance.
Applications - Buildings: Water lifting and supply for buildings and apartments, heating and cooling - Water supply: Water lifting and supply for simple water supply systems - Factories: Industrial water lifting and supply, for general industrial machinery sets - Others: General water lifting and drainage Easy maintenance - Since it is a motor-integrated type, there is no concern about misalignment due to starting and stopping during operation, and there is no need for alignment. - Thanks to the B.P.O. (Back Pull-Out) structure, disassembly and assembly can be done without changing the suction and discharge piping. - The use of mechanical seals in the shaft sealing section makes maintenance easy. Low noise and space-saving design The two-pole motor design is compact and lightweight, yet achieves low noise levels comparable to four-pole motors. High efficiency and energy-saving product By pursuing the ideal flow of water through computer analysis, we have achieved high efficiency with uniquely shaped impellers and casings. Corrosion-resistant design The use of bronze impellers and stainless steel shafts enhances corrosion resistance. Model numbers marked with * in the standard specifications section do not have standard specification points.
Inquire About This Product
basic information
- Multi-stage structure compatible with high lift - Integrated motor design eliminates the need for alignment; can be disassembled and assembled with suction and discharge piping intact due to B.P.O. structure - Mechanical seal adopted at the shaft sealing section for easy maintenance - Two-pole motor design for compactness and lightweight, with low noise comparable to four-pole motors - Bronze impeller and stainless steel shaft improve corrosion resistance
Price range
Delivery Time
Applications/Examples of results
It is used for pumping and supplying water for buildings and apartments, pumping and supplying water for simple water supply systems, and industrial water supply and drainage in factories. It is suitable for water supply and drainage equipment that requires high lift, maintenance, and corrosion resistance.
Line up（7）
| Model number | overview |
|---|---|
| 40x32-E52.2 | |
| 40x32-E52.2H | |
| 40x32-E53.7 | |
| 40x32-E53.7H | |
| 50x40-E53.7 | |
| 50x40-E53.7H | |
| 50x40-E55.5 |
