High-speed rotation compatible die height counter that contributes to reducing mold exchange time.
We have developed a counter that can withstand high-speed rotation while maintaining the mechanical measurement mechanism that many customers have requested. The mechanism we adopted is the "Geneva mechanism." By using this mechanism, we have been able to increase the allowable rotation speed by approximately twice for various 5-digit specifications (3 digits for the integer part + 2 digits for the decimal part). It can currently be replaced with the counters you are using.
Inquire About This Product
basic information
"Z Series Allowable Rotational Speed" [MTS-1300-5Z/MTS-145-5Z] Recommended rotational speed: 400 rpm (standard type: 200 rpm) Momentary maximum speed: 900 rpm (standard type: 600 rpm) [MTS-2500-5Z/MTS-190-5Z] Recommended rotational speed: 400 rpm (standard type: 200 rpm) Momentary maximum speed: 750 rpm (standard type: 500 rpm) *In the case of square key and flexible shaft specifications, there is a risk of reduced durability for the square key and flexible shaft. *High-speed rotation test conducted at 1250 rpm. *Continuous operation test conducted for 120 minutes.
Price range
Delivery Time
Applications/Examples of results
- It can be replaced from the counter you are currently using. - Customers who had to limit speed due to the low allowable rotation speed of the standard 5-digit specification. - It can be replaced with a bolt-on method by improving only the internal mechanism.
Company information
Modern industries require environmental durability. We support modern industries with precision measurement and instrumentation. Wako Seiki Co., Ltd. manufactures measuring instruments for various industrial fields that require durability and robustness, such as seismic resistance, shock resistance, dustproofing, and oil resistance. Mechanical counters are used in various applications, including die height counters used as positioning devices for forging machines, servo motors, brake motors, feeding devices, reduction amount gauges, control motors, feeding length counters, grip coefficient counters, and plate thickness display counters. Furthermore, we have started selling a hybrid absolute encoder that combines mechanical measurement mechanisms with digital signal output mechanisms for precise displacement position measurement. Digital scales, which can be utilized for slide position measurement like linear scales, and three-dimensional positioning measurement linked with XYZ axes can be applied in various ways. As a specialized company in precision measuring instruments, we contribute to the industrial development of Japan and the world.
