Install a vent pipe on the lid! This water supply and shut-off mechanism is also used in toilet tanks and similar applications.
This is a custom-made case of a tapered stainless steel container used for the storage and supply of purified water delivered to a pharmaceutical manufacturer. The ball tap is equipped with a float ball, which lowers when the water in the tank decreases, automatically starting the water supply. When the water supply is activated, the float ball rises and stops the water supply at approximately 100 liters. Additionally, the container adopts a tapered design that slopes towards the outlet, allowing water to flow out smoothly until the very last drop. 【Case Overview】 - A stainless steel ball tap is installed for automatic water supply. - The mechanism for water supply and stop is also used in toilet tanks, etc. - A level sensor is attached to the helix on the lid for monitoring. - A vent pipe is installed on the lid. - A cheese fitting is attached to the outlet, allowing connection to two pipes. *Other cases can be viewed via "PDF Download." *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Product Specifications】 ■Dimensions: Inner diameter φ565mm × H1050mm ■Capacity: Full water 150L (stopping water approximately 100L) ■Material: SUS304 ■Surface treatment: #320 buff polished inside and outside ■Others: Ball tap, Heller cheese, Heller vent *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
Company information
Our company, which started in 1957 with the aim of manufacturing stainless steel products and containers for home use, has since expanded into the production and sale of stainless steel tanks for industrial fields such as pharmaceuticals, chemicals, and food. Currently, we design, manufacture, and sell small to medium-sized stainless steel tank units across various industries. Moving forward, as a manufacturer of stainless steel containers and mixers (stirring devices), we will continue to challenge ourselves with sincerity, enthusiasm, and creativity to deliver "one-of-a-kind" products and services to our customers, advancing step by step into the future.
