The joy of freely designing structures, the coherence of connections, and the expanding possibilities.
ASCAL is a program that performs consistent structural calculations for buildings recognized by axes that are not constrained by a grid. It is an unprecedented program that combines the ease of input for a consistent design program based on layers and axes with the freedom of arbitrary shape input offered by a general-purpose analysis program. Furthermore, if there are slabs and beams capable of load transfer, it automatically performs load calculations for any arbitrary shape. Whether for buildings, plant structures, or bridges, it supports consistent calculations from load calculations to stress calculations, capacity calculations, and the creation of calculation documents, enabling a free and enjoyable visualization of building structures. 【Ministerial Certification Obtained】 ○ RC Structure Primary and Secondary Design (Public Interest Incorporated Foundation Japan Architectural Center Performance Evaluation (BCJ Evaluation - CP0068-02) / Ministerial Certification (TPRG-0104)) ○ S Structure Primary and Secondary Design (Public Interest Incorporated Foundation Japan Architectural Center Performance Evaluation (BCJ Evaluation - CP0090-01) / Ministerial Certification (TPRG-0105)) ○ Wall-type Structure Primary and Secondary Design (Public Interest Incorporated Foundation Japan Architectural Center Performance Evaluation (BCJ Evaluation - CP0091-01) / Ministerial Certification (TPRG-0106)) For more details, please contact us or download the catalog.
Inquire About This Product
basic information
【Features】 ○ Obtained ministerial certification (old) ○ In Ver.6, performs integrated structural calculations for RC, steel, and wall-type RC buildings (load calculations, stress calculations, section calculations, and capacity lateral resistance calculations) ○ Capable of handling mixed structures of wall-type RC and steel, RC with the top floor in steel, lower floors in wall-type RC, or the first floor in RC and two or more floors in wall-type RC ○ SRC structures are analyzed up to stress calculations ○ Conducts structural calculations (primary design, secondary design) in accordance with the Building Standards Act, its enforcement order, and notifications ○ Input is designed to be visually understandable, utilizing the Windows GUI environment ○ Stress calculations are performed through complete three-dimensional analysis ○ Calculates capacity lateral resistance through load increment analysis of a fully three-dimensional model based on the rigid floor assumption ● For more details, please contact us or download the catalog.
Price information
Please contact us.
Delivery Time
※Please contact us.
Applications/Examples of results
【Target Structures】 ○ Truss Roof ○ Arbitrary Shape ○ Self-Driving Parking Lot ○ RC/Walled Mixed ○ Material Axis Eccentricity ● For more details, please contact us or download the catalog.
