Achieve functional expansion by adding components! Suitable for checking the unevenness of the circuit board and observing liquid flow and droplet conditions.
This product is a high-precision dispenser using a twin-air system, capable of handling everything from dispensing units to system integration. Equipped with a top view, side view, Z-axis electric drive, laser displacement meter, and constant temperature function, it is suitable for confirming the unevenness of substrates, checking the gap with the nozzle tip, and observing liquid flow and deposition conditions. We offer a lineup including the "ES series" for R&D to production, the "WLC and MLC series" for prototyping, mass production automation, and custom systems, as well as the tabletop robot type "ED series." 【Features】 ■ Capable of handling everything from dispensing units to system integration ■ Diverse function expansions (custom systems available) - Auto alignment - Simple dimension measurement after coating/drawing - Shape inspection and coating quality assessment - Video/still image capture during coating *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Response Content】 ■Various adhesives: Fine and ultra-fine application (manufacturing of electronic components, EV-related parts, smartphones, etc.) ■Ag, Au, Cu (nano) paste: Fine wiring, local wiring, screen printing disconnection repair ■Solder paste (Type 4-8): Dropping onto micro and fine circuits, grid array formation, repair ■Sealants, insulating materials: Fine frame application for CMOS sensors, organic EL/liquid crystal panels, power devices, etc. ■Conductive resin materials: Electrode formation for quartz oscillators, MEMS, LEDs, etc., local wiring inside cavities ■Polyimide, epoxy: Wafer passivation, guard rings, wire bonding reinforcement *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
【Examples of Coating and Application】 ■ Silicone Adhesive 50μm Width ■ UV Curing Resin 38μm Diameter ■ Silicone Resin (500Pa·s) ■ Ag Nano Paste 50μm Width ■ Ag Nano Paste 70μm Diameter ■ Solder Paste 60μm Diameter ■ Conductive Adhesive 50μm Diameter *For more details, please refer to the PDF document or feel free to contact us.
Company information
Engineering Lab, as a professional in fine coating, develops, manufactures, and sells precision coating equipment. We offer a lineup specialized in precision coating, including the "Twin Air Dispenser," which utilizes patented technology to achieve the world's smallest coating, the high-speed precision coating piezo jet dispenser "X-JET," and the "Spiral Coater," which allows spray coating without the need for masking. We enable high-precision micro-coating of high-viscosity liquids that was difficult with conventional technology, achieving ultra-fine coating with a minimum application amount of 20 pL. Additionally, Engineering Lab offers a wide range of inline fully automatic coating equipment suitable for mass production and tabletop coating devices suitable for R&D, providing the optimal coating equipment according to application and work size.
