A flagship model equipped with all functions, the best ultrasonic thickness gauge that is highly accurate and powerful.
The CMX3-DL is the flagship model of ultrasonic thickness gauges, equipped with all the features of the MX2-DLとCMX1-DL, achieving a resolution of 0.001mm and a measurement range of 10m. It includes various features such as A/B scope display, independent three gates, automatic temperature compensation, scan mode, and a 8GB data logger. Additionally, the new GAIN SLOPE (TDG) function corrects sensitivity reduction based on propagation time, allowing for more accurate measurements of thick materials and high-damping materials like FRP and rubber than ever before. It also has a film thickness measurement mode, enabling simultaneous measurement of wall thickness and film thickness. ■ Features - Flagship model of ultrasonic thickness gauges - A-scope displaying ultrasonic waveforms and B-scope displaying cross-sectional images - Compatible with both dual-transducer and single-transducer probes - High-resolution mode of 0.001mm - 'GAIN SLOPE' function optimal for measuring high-damping materials and thick objects
Inquire About This Product
basic information
■Specifications - Measurement range (steel equivalent): 0.63 to 10,000 mm (Pulse-Echo mode) - Thick film thickness measurement range: 0.013 to 2.54 mm - Display resolution: 0.001 mm - Sound speed measurement range: 310 to 18,542 m/s - Measurement modes: Pulse-Echo, Pulse-Echo + Thickness, Pulse-Echo + Temperature Compensation, Echo-Echo, Multi-Echo, Thickness - Probe: Single transducer probe / Dual transducer probe - Screen update: Color model 60 times/second, Monochrome model 25 times/second - Dimensions: 64 (W) × 165 (L) × 32 (D) mm - Weight: Approximately 383 g (including battery) - IP rating: IP65 (dustproof and drip-proof) - Power supply: Three AA alkaline batteries, USB power supply - Warranty period: 2 years (warranty applies to the main unit only) - Functions: Material list (38 items), Setup (64 items) Scan mode, Transducer auto-recognition, Automatic zero adjustment Screen capture, Data logger (8GB), etc. *For more details, please refer to the PDF document or contact us.*
Price range
P4
Delivery Time
P4
Applications/Examples of results
■Thickness measurement of metals such as iron, stainless steel, aluminum, castings, as well as glass, plastic, and ceramics ■Thickness measurement of high-damping materials such as rubber and FRP ■Thickness measurement of the substrate (base material) from the coating surface ■Measurement of film thickness
