Maximum opening length of 6.6m! Suitable for horizontal suspension of long pipes! Swing-type simple earth retention.
The speed of underground construction work has dramatically improved! With swing fittings, the lifting and lowering of buried objects is achieved in a "horizontal," "safe," and "efficient" manner!
Do you have any of the following concerns when performing burial work for large-diameter long pipes or box culverts using conventional steel sheet piles and retaining materials? - I want to reduce the installation effort for the retaining wall. - It is difficult to construct due to environmental issues such as overhead power lines. - I want to secure the opening height from the excavation bottom for projects like box culverts. - The transportation costs for retaining materials are high. - I want to avoid welding work on-site as much as possible. The "Quick Retaining Box Type 36 Panel" can solve these problems. The cutting beam can swing, allowing for horizontal lowering of buried objects up to a height of 1.35 meters. Additionally, the maximum opening height for the lowest section can be secured at 2.9 meters. It can accommodate excavation depths of up to 6.0 meters for sandy soil and up to 4.5 meters for clayey soil. Furthermore, being a unit type that is easy to install and remove simplifies the process, improves cost-effectiveness and on-site work speed, and enhances safety. 【Features】 - Proven record of reducing work processes by over 50% - Proven record of improving cost-effectiveness by over 30% - Unique mechanism allows for swinging of the cutting beam - Installation and removal possible without welding - NETIS registration: KT-150107-A *For more details, please refer to the PDF document or feel free to contact us.
Inquire About This Product
basic information
【Lineup】 - BOX lower panel deep digging use 3620 - BOX flat panel deep digging use 3620 / 3615 / 3610 / 3605 - BOX lower panel for large diameter use 3020 *For more details, please refer to the PDF document or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the PDF document or feel free to contact us.
