Wakamiya Oodori Park Skate Plaza, Nagoya City, Aichi Prefecture
Seal Hard Skate Park New Construction Specifications
The park, beloved by skaters nationwide, has reopened after renovations!
Under the supervision of the Japan Skateboard Association, the park "Wakamiya Oodori Park Skate Plaza" has opened in Nagoya City, Aichi Prefecture! The area has expanded from the previous 1,100 square meters to 2,500 square meters. It has been developed into three areas: "Beginner," "Park," and "Street," providing an environment where both beginners and advanced users can enjoy. Not only skateboarding, but BMX and inline skating are also available. There is also a designated space for guardians to watch over. At the opening, many skaters enjoyed their first rides, and it has been reported that the number of users has been increasing since then. I hope that being involved in such a historically significant park will help convey the quality of the surface to many people.
Inquire About This Product
basic information
The "Seal Hard Skate Park Specification" is a construction method product provided in the following steps 1 to 4. [Patent pending] ◆1. Concrete Grinding (Renovation only) The roughened concrete surface is shaved down to remove surface irregularities. ◆2. Concrete Polishing For newly installed concrete: Smooth out trowel marks, trowel lines, and fine irregularities on the surface to create a smooth surface without roughness. For renovated concrete: Further smooth out grinding marks and fine irregularities from the surface that has been made even in the previous step, creating a smooth surface without roughness. ◆3. Penetrating Surface Hardener Seal Hard This is a concrete surface hardener that "penetrates" rather than "coats." It provides strong dust resistance and wear resistance to the concrete. By not creating a film on the concrete surface and densifying the internal layers, it results in a concrete floor finish that is free from peeling. ◆4. Water Absorption Inhibitor (Water Repellent) Aquapel Plus This is a concrete surface water absorption inhibitor (water repellent) that "penetrates" rather than "coats." By not creating a film on the concrete surface and imparting water-repellent properties to the internal layers, it maintains water absorption inhibition effects for a long time as long as the surface does not wear down.
Price information
The price varies depending on the construction area and the roughness of the surface. For more details, please contact us.
Delivery Time
※The construction period may vary depending on the construction timing and area, so please contact us for more details.
Applications/Examples of results
"Skate Park Achievements" - Nagao Skate Park (Sanuki City, Kagawa Prefecture) - Sumida Skateboard Park (Sumida Ward, Tokyo) - AKAKEN PARK (Kanazawa City, Ishikawa Prefecture) - NiX Urban Sports Park (Toyama City, Toyama Prefecture) - Green Park Daimon Skateboard Square (Imizu City, Toyama Prefecture) - Toyo Carbon Urban Sports Park (Marugame City, Kagawa Prefecture) - Ibaraki Electrical Construction Skateboard Park Ishio (Ishioka City, Ibaraki Prefecture) - Chausuyama Skate Park (Nagano City, Nagano Prefecture) - Gruun Gamagori Skate Park (Gamagori City, Aichi Prefecture) - Skate Park within the Miyoshi Town Hall Grounds (Miyoshi Town, Iruma District, Saitama Prefecture) - Musashino Park Skateboard Square (Fuchu City, Tokyo) - Wakamiya Oodori Park Skate Park (Nagoya City, Aichi Prefecture) - Skate Park Obu (Obu City, Aichi Prefecture) - Osawa Comprehensive Ground Skateboard Area (Mitaka City, Tokyo) - Awaji City Skateboard Park (Awaji City, Hyogo Prefecture) - Hinai-gata Park Skateboard Park (Kyoto City, Kyoto Prefecture) Others / 6 cases
Detailed information
-
【SSP-100 Joint Filler】 The polyurea resin-based concrete joint filler "SSP-100" is a fast-setting concrete joint filler. By filling and protecting the joints, it prevents damage to the joint areas.
-
Surface Grinding A diamond blade is mounted on a large grinding machine to remove the weak surface layer in advance and finish it smoothly.
-
【Seal Hard Application】 We will apply the penetrating concrete surface hardener "Seal Hard." With the effect of Seal Hard, the concrete surface will gradually harden and change. Since Seal Hard is a non-film-forming penetrating type, it will not peel off. However, penetrating hardeners are vulnerable to rainwater, and when exposed to rain, the penetrating components may dissolve and wash away.
-
Cleaning
-
【Application of Aquapel Plus】 The penetrating water-repellent agent "Aquapel Plus" will be applied. By applying Aquapel Plus, we compensate for the weaknesses of seal hard that are vulnerable to rain, transforming it into a strong, rain-resistant concrete. Since it is a non-film-forming penetrating type, it will not peel off.
catalog（6）
Download All Catalogs![[Seal Hard - Skate Park Specification] Concrete surface finish suitable for skate parks | Wear-resistant | Water absorption suppression | Long lifespan](https://image.www.ipros.com/public/catalog/image/01/558/693096/IPROS44690527504882566076.jpeg?w=120&h=170)
![Seal Hard Skate Park Specifications [Design Price List]](https://image.www.ipros.com/public/catalog/image/01/5b5/795655/IPROS1552997852609110194.jpeg?w=120&h=170)
CAD data（1）
| Model number | overview | File |
|---|---|---|
| Standard Drawing for Skate Park Surface Specifications | The "Seal Hard Skate Park Specification" is a construction method provided in the following steps 1 to 4. [Patent pending] ◆1. Concrete grinding (for renovation only) ◆2. Concrete polishing ◆3. Penetrating surface hardener Seal Hard ◆4. Water absorption suppressor (water repellent) Aquapel Plus This is a pavement specification created based on past achievements. Please feel free to copy and use it when designing future skate parks. |
|
