Sagamihara Gion Urban Sports Park, Sagamihara City, Kanagawa Prefecture
Seal Hard Skate Park New Construction Specifications
The park that produced many Olympic athletes has reopened after renovations!
Under the supervision of the NPO Japan Skate Park Association, the skate park "Sagamihara Gion Urban Sports Park" has opened in Sagamihara City, Kanagawa! It boasts an area of approximately 3,000 square meters and is a facility specialized in street sports. The environment is enjoyable for everyone from beginners to advanced users, and not only skateboarding but also BMX and inline skating are available. It is a facility that attracts many promising skaters and riders, making it a great place to watch. The opening ceremony was lively, with many attendees, including Olympic gold medalist Koi Yoshizawa and athlete Fujisawa. It was a wonderful opportunity for many people to experience our surface firsthand, and we are thrilled to have been able to construct this park.
Inquire About This Product
basic information
The "Seal Hard Skate Park Specification" is a construction method product provided through the following steps 1 to 4. [Patent pending] ◆1. Concrete Grinding (Renovation only) The roughened concrete surface is shaved down to remove surface irregularities. ◆2. Concrete Polishing For newly installed concrete: Smooths out trowel marks, trowel lines, and fine irregularities on the surface to create a smooth finish without roughness. For renovated concrete: Further smooths out grinding marks and fine irregularities from the surface that has been made even in the previous step, creating a smooth finish without roughness. ◆3. Penetrating Surface Hardener Seal Hard This is a concrete surface hardener that "penetrates" rather than "coats." It provides strong dust resistance and wear resistance to the concrete. Since it does not create a film on the concrete surface but densifies and strengthens the internal layers, it results in a concrete floor finish that is free from peeling. ◆4. Water Absorption Suppressor (Water Repellent) Aquapel Plus This is a concrete surface water absorption suppressor (water repellent) that "penetrates" rather than "coats." It does not create a film on the concrete surface but imparts water-repellent properties to the internal layers, allowing for long-term water absorption suppression effects as long as the surface does not wear down.
Price information
The price varies depending on the construction area and the roughness of the surface. For more details, please contact us.
Delivery Time
※The construction period may vary depending on the construction schedule and area, so please contact us for more details.
Applications/Examples of results
"Skate Park Achievements" - Nagao Skate Park (Sanuki City, Kagawa Prefecture) - Sumida Skateboard Park (Sumida Ward, Tokyo) - AKAKEN PARK (Kanazawa City, Ishikawa Prefecture) - NiX Urban Sports Park (Toyama City, Toyama Prefecture) - Green Park Daimon Skateboard Square (Imizu City, Toyama Prefecture) - Toyo Carbon Urban Sports Park (Marugame City, Kagawa Prefecture) - Ibaraki Electric Construction Skateboard Park Ishioka (Ishioka City, Ibaraki Prefecture) - Chausuyama Skate Park (Nagano City, Nagano Prefecture) - Gruun Gamagori Skate Park (Gamagori City, Aichi Prefecture) - Skate Park within the Miyoshi Town Hall Grounds (Miyoshi Town, Iruma District, Saitama Prefecture) - Musashino Park Skateboard Square (Fuchu City, Tokyo) - Wakamiya Oodori Park Skate Park (Nagoya City, Aichi Prefecture) - Skate Park Obu (Obu City, Aichi Prefecture) - Osawa Comprehensive Ground Skateboard Area (Mitaka City, Tokyo) - Awaji City Skateboard Park (Awaji City, Hyogo Prefecture) - Hinai-gata Park Skateboard Park (Kyoto City, Kyoto Prefecture) Others / 6 cases
Detailed information
-
Surface Grinding A diamond blade is attached to a large grinding machine to remove the weak surface layer in advance and achieve a smooth finish.
-
【Seal Hard Application】 The penetrating concrete surface hardener "Seal Hard" will be applied. With the effect of Seal Hard, the surface of the concrete will gradually harden and change. Since Seal Hard is a non-film-forming penetrating type, it will not peel off. However, penetrating hardeners are vulnerable to rainwater; when exposed to rainwater, the penetrating components can dissolve and wash away.
-
Cleaning
-
【Application of Aquapel Plus】 The penetrating water-repellent agent "Aquapel Plus" will be applied. By applying Aquapel Plus, we compensate for the weaknesses of seal hard that are vulnerable to rain, transforming it into a strong, rain-resistant concrete. Since it is a non-film-forming penetrating type, it will not peel off.
catalog（6）
Download All Catalogs![[Seal Hard - Skate Park Specification] Concrete surface finish suitable for skate parks | Wear-resistant | Water absorption suppression | Long lifespan](https://image.www.ipros.com/public/catalog/image/01/558/693096/IPROS44690527504882566076.jpeg?w=120&h=170)
![Seal Hard Skate Park Specifications [Design Price List]](https://image.www.ipros.com/public/catalog/image/01/5b5/795655/IPROS1552997852609110194.jpeg?w=120&h=170)
CAD data（1）
| Model number | overview | File |
|---|---|---|
| Standard Drawing for Skate Park Surface Specifications | The "Seal Hard Skate Park Specification" is a construction method provided in the following steps 1 to 4. [Patent pending] ◆1. Concrete grinding (for renovation only) ◆2. Concrete polishing ◆3. Penetrating surface hardener Seal Hard ◆4. Water absorption suppressor (water repellent) Aquapel Plus This is a pavement specification created based on past achievements. Please feel free to copy and use it when designing future skate parks. |
|
Company information
The Wilby Building Materials Division is a professional group specializing in sports facility construction and flooring finishing work. 【Building Materials Division】 ● Sports Facility Business: Centered in Hokuriku and Niigata, we engage in specialized construction related to sports facilities such as swimming pools and gymnasiums, as well as flooring work for various facilities. ● Building Sales Business: We provide high-value flooring products that are not available in conventional offerings, such as scratch-resistant flooring "Cattina" and natural wood composite flooring "Alpito." ● Good Floor Business: As the domestic importer of concrete chemical products from the U.S. company LATICRETE, we offer various concrete flooring solutions, including "Seal Hard." ● Environmental Business: We propose and sell installation services for products such as "Painted Insulation Material Gain," "Cool Roof," "Seismic Ceiling WILL-TEC Method," and "Nano Zone Coat." 【Construction Division】 We construct numerous low-cost steel frame buildings for logistics facilities such as distribution centers and warehouses, as well as commercial facilities like supermarkets, home centers, drugstores, and fashion malls throughout Japan. We provide consistent services tailored to customer needs, including land development, design, and comprehensive construction.
