Even designers and contractors can check for interference while designing rebar using a 3D model!
"Site Navigation 3D Rebar" is a rebar design program that automatically converts structural design rebar into a three-dimensional model by importing BIM data (ST-Bridge). It allows for the adjustment of the positions of main rebar for columns and beams on the layout plan, verification of main rebar anchorage dimensions, and rebar design while checking the arrangement and interference of rebar in the three-dimensional model. Additionally, a high-spec PC is not required. If the CPU is at least a Core i5 or Ryzen 5 class, it will run comfortably on a laptop. 【Features (partial)】 ■ Rebar design for steel column footings (compatible with prefabricated and conventional base plates) is possible ■ Rebar design for reinforced concrete structures can be performed ■ Seismic isolation components can be placed on the lowest floor ■ New input of rebar for RC components and S components is also possible ■ Can be operated by designers and contractors, no dedicated operator is required *For more details, please refer to the related links or feel free to contact us.
Inquire About This Product
basic information
【Other Features (Partial)】 ■ Easily add or modify structural cross-sections (piles, foundations, columns, beams, slabs, and bearing plates), cover, and reinforcement ■ Adjust the position of rebar by dragging it on the layout ■ Display a 3D model with one click to check reinforcement and interference ■ Reset the automatically designed anchorage length while checking against specified values *For more details, please refer to the related links or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please refer to the related links or feel free to contact us.
