Hitachi Industrial Equipment Systems Feedback Cubicle (Front Maintenance Slim Type)
Hitachi Industrial Equipment Systems
Thin high-voltage distribution cubicle that can be installed flush against the wall, with maintenance completed through front access.
Overview Compared to conventional feedback cubicles, the installation area is reduced by approximately 20%, allowing for diverse layouts. Additionally, the cubicle can be structurally modified to meet rear inspection needs. Maintenance inspections and operational access are completed from the front, enabling a slim cubicle that can be installed flush against walls. Cubicle Features - Adopts an air-insulated method that makes maintenance and inspections easy. - Achieves significant miniaturization. Built-in Features - In consideration of installations in electrical rooms where cable pits cannot be constructed, the main circuit and control circuit cables adopt an upward connection structure. - No inspection or work space is required on the rear side, greatly improving layout flexibility in limited spaces. - Standard equipment includes a hybrid vacuum circuit breaker (VCB), digital protective relay (ICU), and multi-CT. Built-in Features - Hybrid VCB: Adopts a hybrid operating mechanism that combines permanent magnets and electromagnets, eliminating the need for lubrication work on the mechanism, thus achieving low maintenance. - ICU + Multi-CT: By combining ICU with multiple protective elements and multi-CT, detection accuracy is guaranteed over a wide range, accommodating multiple rated primary currents.
Inquire About This Product
basic information
- Approximately 20% reduction in installation area compared to conventional methods - Maintenance and inspection can be completed with front access, allowing for wall-mounted installation - No need for rear inspection space due to air insulation method - Main circuit and control circuit cables have an upward connection structure - Standard equipment includes hybrid VCB, digital protective relay (ICU), and multi-CT
Price range
Delivery Time
Applications/Examples of results
It is used for high-voltage power distribution equipment in factories and buildings. It is suitable for electrical rooms where cable pits cannot be constructed and for sites where installation is required in limited spaces.
