Hitachi Industrial Equipment Systems Programmable Controller MICRO-EHV
Hitachi Industrial Equipment Systems
All-in-one compact PLC with standard USB and serial interfaces, expanded functionality.
High-performance all-in-one compact PLC MICRO-EHV Equipped with standard USB port for PC connection and serial port (RS-232C), the standard version also includes a 20-point type model, standard Ethernet port, and enhanced "usable features" such as program reading/writing with general-purpose USB memory, data logging, and tracing. Common features of both high-performance and standard versions: - Standard USB port for PC connection and serial port (RS-232C) - Expandable input/output points with various expansion units - All models support communication option boards and analog input/output option boards - Easy connection to inverters, stepping motors, and temperature controllers - Battery-less data retention function (256 words) - Battery-less program retention, with various comments also saved in the PLC - High-speed counter, pulse/PWM output - Compatible with user-friendly programming software Control Editor - Easy programming with clear instruction descriptions - I/O numbers use an easy-to-understand fixed address method - Input/output refresh prohibition function and constant scan function - Uses a detachable terminal block common with MICRO-EH - Password protection at the sheet level
Inquire About This Product
basic information
- Standard equipped with USB port for PC connection and serial port (RS-232C) - Expandable input/output points with various expansion units, supports communication and analog input/output option boards - Battery-less data retention (256 words), battery-less program retention - Supports high-speed counters, pulse/PWM output - High-function version comes standard with Ethernet port, program reading/writing via USB memory, data logging, and tracing support
Price range
Delivery Time
Applications/Examples of results
It is used for device control in combination with inverters, stepping motors, temperature controllers, and so on. It is suitable for small to medium-sized equipment that requires compact and multifunctional PLCs.
Line up（2）
| Model number | overview |
|---|---|
| MVH | |
| MVL |
