An era where on-site management utilizing the universe is commonplace.
Positioning accuracy… a few millimeters to a few centimeters! Since observations are made using GNSS, height measurements can be taken! This can be used for dynamic observation of cut and fill during construction, monitoring of tunnel construction entrances, dynamic observation of infrastructure structures, displacement measurement of soil walls in retaining wall construction, and impact assessment on adjacent buildings due to excavation work in urban areas, among other applications. 【Features】 ■ Strong against obstacles, capable of positioning even in narrow fields of view ■ Easy installation, maintenance-free ■ Low cost and high-precision positioning
Inquire About This Product
basic information
【Specifications】 ■GNSS Receiver: Septentrio Mosaic X5 ■GNSS Antenna: Yokowo YOZ-52728 ■Power Consumption: 3.0W ■Waterproof Rating: Equivalent to IP65 ■Power Supply: PoE (Power over Ethernet) (up to 4 units can operate) ■Communication: PoE LAN (100BASE-T) ■Dimensions: W125×D125×H100mm (excluding protrusions) ■Weight: 785g (excluding mounting fixtures)
Price range
Delivery Time
※Please feel free to contact us.
Applications/Examples of results
It can be used for monitoring the dynamics of cut and fill during construction, monitoring the entrance of tunnel construction, monitoring the dynamics of infrastructure structures, measuring the displacement of soil walls in retaining wall construction, and assessing the impact on adjacent buildings due to excavation work in urban areas.
catalog（1）
Download All Catalogs
Company information
Our company rents out approximately 1.05 million items across about 4,800 types of civil engineering, construction, and industrial-related machinery. In addition, we also engage in the development, manufacturing, and sales of our own products. With a motto of a paid volunteer spirit, we are constantly planning and developing new products to meet the diverse needs of our customers through our nationwide sales network of 240 locations.
