Stable distribution of one antenna signal to four systems. A professional model that optimizes the wireless environment.
● UD-554 (UD554) is a receiving 4-way splitter manufactured by Nippon Antenna, operating in the frequency range of 350 to 470 MHz. ● It is a receiving 4-way splitter for radio equipment. ● The operating frequency is 350 to 470 MHz. ● The model number changes depending on the type of connector. - NJ connector: UD-554 N-J * The BNC-J connector type UD-554 BNC is no longer in production. * For more details, please feel free to contact our company.
Inquire About This Product
basic information
●This is a made-to-order product. ●Specifications ・Device Type: 4-way splitter for reception ・Model Name: UD-554 ・Operating Frequency: 350–470MHz ・Input/Output Impedance: Nominal 50Ω ・VSWR: 1.5 or less ・Split Loss: 7.0dB or less ・Isolation: 20dB or more ・Maximum Allowable Power: 250mW ・Operating Temperature Range: -10℃ to +50℃ ・Input/Output Connector: N-J type or BNC-J *as specified ・Configuration: Matching transformer type ・Weight: Approximately 0.6kg ・Product Code: 2057421 ●There are also the following splitters manufactured by Japan Antenna: ・60MHz Band Special Split Ratio Power Splitter D-060S ・400MHz Band Special Split Ratio Power Splitter D-400S ・4-way splitter for reception 40–270MHz VD-554 ・60MHz Band 2-way Splitter D-0601 ・150MHz Band 2-way Splitter D-1501 ・260MHz Band 2-way Splitter 260–275MHz D-2601 ・400MHz Band 2-way Splitter D-4001 ・900MHz Band 2-way Splitter D-9301 *For more details, please feel free to contact us.
Price information
Manufacturer's price: 73,500 yen (excluding tax) We aim to sell at a lower price than anywhere else. Please contact us for our selling price.
Price range
P2
Delivery Time
Applications/Examples of results
【Examples of Use】 ■ Security companies and monitoring centers ■ Traffic control centers ■ Command rooms and disaster prevention centers ■ Municipal disaster prevention radio reception facilities ■ Fire stations and emergency command rooms ■ Police stations and wide-area communication management rooms ■ Factories and manufacturing line monitoring rooms ■ Warehouses and logistics centers ■ Port facilities, airports, and railway facilities ■ On-site management offices at construction sites ■ Building management companies and facility management rooms ■ Shopping mall broadcasting rooms ■ Event venues and event operation headquarters ■ Management rooms in hotels and large commercial buildings ■ Internal management and facility management rooms in hospitals ■ Broadcasting stations (reception monitoring equipment) ■ Amateur radio clubs ■ Educational institutions (radio operation, research labs, disaster prevention training) ■ Internal operations at museums and theme parks ■ Neighborhood associations and community centers, etc.
