Ultra-lightweight 8.9kg! High strength 19KN! Easy to carry for anyone. Resistant to rust, allowing for long-term use and total cost reduction [Patent obtained].
"Alpa" is a lightweight aluminum temporary support post that anyone can easily carry. Compared to the conventional model weighing 14.2 kg, the Alpa 45 (Type 70) is ultra-light at just 8.9 kg. It can be safely handled by those who may lack physical strength, such as women and elderly workers. In 2025, we will release the Alpa 45 (Type 60 and Type 50). The Type 50 achieves a weight reduction to 7.1 kg while maintaining a load capacity of 19 kN. We also offer the Alpa 75 with a load capacity of 36 kN. 【Features】 ■ Conventional model 14.2 kg → Ultra-light 8.9 kg (Alpa 45) ■ Conventional model 14.7 kN → High strength 19 kN (Alpa 45) ■ Can be used without connections due to the insertion pipe method ■ The length of the post can be manufactured to your desired specifications (Types 90, 70, 60, 50, 40, 30) ■ Patents obtained in various countries (Japan, Europe, UK, Australia, China) *For more details, please download the PDF or feel free to contact us.
Inquire About This Product
Related Videos
basic information
【Specifications (Excerpt)】 ■Alpa 45 (70 model) ■Length (mm): Minimum 2,300, Maximum 3,490 ■Allowable Load (KN) ・Upper and Lower Flange Material: 14.0 ・Upper and Lower Flange Material, Lower End Concrete: 19.0 *For more details, please download the PDF or feel free to contact us.
Price range
Delivery Time
Applications/Examples of results
For more details, please download the PDF or feel free to contact us.
catalog（1）
Download All Catalogs
Company information
Forbill Co., Ltd. focuses on the formwork business and is also engaged in the production of construction materials, providing support for on-site production. We will strive to be of service to everyone by thinking about buildings and dedicating ourselves to them for the sake of the buildings.
