A simple and powerful security system! Prevents theft with duplicated keys.
It is a simple yet powerful security system that protects important vehicles and construction machinery from unauthorized engine starts. Once security is activated, the engine will not start even if duplicate keys, direct wiring, or an immobilizer cutter are used. ■ Compatible with 12V to 24V! It can be easily installed in a wide range of vehicles and heavy machinery, from ordinary cars to trucks, dump trucks, cranes, agricultural machinery, construction equipment, and rental vehicles. It is a trusted product with over 10 years of extensive delivery experience. ■ Zero battery burden & excellent cost-effectiveness There is no standby current, so the battery is not burdened at all even if the vehicle is not used for a long time. The running cost is very economical, requiring only the remote control battery replacement about once a year. ■ Easy operation with just one button After the engine stops, security is automatically activated immediately. Deactivation is as simple as pressing a button on the dedicated remote key. There is no concern about malfunction due to radio interference, and the compact main unit can be installed anywhere inside the vehicle. *For more details, please feel free to contact us. https://www.joqr-bkc.co.jp/contact_media.php
Inquire About This Product
basic information
【Basic Specifications】 Supported Power Supply: DC12V to 24V compatible (suitable for regular cars, trucks, various construction machinery, agricultural machinery, etc.) Operating Environment: -30 to 80 degrees (excellent heat resistance suitable for extreme cold areas to hot car interiors) 【Main Unit】 Dimensions: 92×58×18mm (compact size that can be hidden in inconspicuous places in the car) Current Consumption: 12mA (during operation) *No standby current, so there is no burden on the battery 【Remote Key (2 included)】 Dimensions: 56×36×13mm Battery Used: DC3V (CR2032 × 1) Current Consumption: 0.044mA (very economical with battery replacement approximately once a year) 【Functions and Options】 Smart Key Registration: Up to 10 remote keys can be registered Options: Anti-theft device installation sticker, master key production 【Installation Precautions】 If the current value is 15A or more for vehicles with a 24V relay, relay replacement is necessary. For ignition system current values when the key is ON, it is recommended to keep it below 10A, and for 24V heavy machinery, around 3 to 5A or less. Due to the precision components, please consider the effects of vibration, water, and heat during installation.
Price information
For more details, please feel free to contact us using the "Contact Us About This Product" button. You can also reach out to us from here: https://www.joqr-bkc.co.jp/contact_media.php
Price range
P3
Delivery Time
Applications/Examples of results
"For the prevention of theft of all vehicles and construction machinery" TORALES is a security system designed to protect valuable assets, such as vehicles, from theft groups and illegal removal. It neutralizes all methods of unauthorized starting, including key duplication, direct wiring, and immobilizer cutting. ■ Main compatible vehicle types and installation scenes It supports power supplies from DC12V to 24V, allowing for a wide range of installations from passenger cars to large construction machinery. ◇ Construction machinery and heavy equipment: Hydraulic excavators, mini excavators, various construction machines (many achievements with construction machine manufacturers and rental companies) ◇ Commercial vehicles and trucks: Trucks, dump trucks, unic trucks, vehicles owned by logistics and transportation companies ◇ Agricultural machinery: Tractors, combines, and other agricultural machines that are often stored outdoors ◇ General vehicles and business cars: Private cars, car lease vehicles, display and inventory vehicles at used car dealerships Construction machinery and commercial vehicles, which are often stored for long periods in locations out of sight, are constantly exposed to the risk of theft. This product has zero standby current, so there is no worry about draining the battery of vehicles that are not moved for long periods, allowing for peace of mind in security measures.
