3.5-inch touch panel equipped display module
Features - Equipped with ESP32-S3 - Wi-Fi/Bluetooth LE compatible (certified for use in Japan) - RS-485 terminal - TF card (SD card) slot - Speaker terminal (with built-in amplifier IC) - Access to a wealth of open-source resources in the ESP32 development environment. Like other ESP32 boards, it is compatible with Arduino IDE.
Inquire About This Product
basic information
Product Name: WT32-SC01 Plus CPU: Dual core Xtensa 32 bit LX17 MCU Memory: Flash: Up to 16MB, PSRAM: Up to 8MB WIFI: 2.4GHz Wi-Fi (802.11b/g/n) (Certified for domestic use in Japan) Bluetooth: Bluetooth 5 (LE) module (Certified for domestic use in Japan) Display LCD: 3.5 inch 320 x 480 LCD Touchscreen: Capacitive Power Input: DC5V / 500 mA (via USB Type-C) Antenna: Built-in Operating Temperature: -20℃ to 70℃ Dimensions: Approximately 92mm x 60mm x 10.8mm Weight: Approximately 100g *This product is under development and specifications may change without notice. Please be aware of this in advance.
Price range
P2
Delivery Time
Applications/Examples of results
Development Examples - EZ KEYpad for digiCamControl Windows 10 version EK-D1 Now on sale on Amazon www.amazon.co.jp/dp/B0BJK8ZPTX - Conference App ZOOM Controller EZ KEYpad for ZOOM EK-Z1 Now on sale on Amazon www.amazon.co.jp/dp/B0B24CD8MG
Detailed information
-
Hardware Interface:
-
Hardware Interface:
