Development, design, and prototype support for carbon heating furnaces exceeding 2,000℃.
We provide development and design technology for heating furnaces and heating systems with 30 years of experience in fiber optic drawing furnaces and vitrification furnaces.
I was part of the Corporate Production Technology Department at Furukawa Electric Co., Ltd. for 26 years, serving as the head of the Production Technology Development Center for 5 years. My main responsibilities included the development of optical fibers and the introduction of equipment into mass production lines, and the equipment I introduced is still actively in use today. From the late 1980s, when I was in charge, until the collapse of the telecommunications bubble, the drawing speed increased every year, and the diameter of the preforms also became larger. At that time, the purchased drawing furnace frequently experienced water leaks, which led us to develop our own drawing furnace. Since there was no design technology for furnaces within the company, I requested a furnace manufacturer we were associated with to design and manufacture the heating furnace. However, water leaks occurred again within a few months. Even when the power to the heating furnace was turned off, the interior was still glowing brightly, and I, being on-site, felt very uneasy. Therefore, I decided to design the heating furnace myself. I incorporated knowledge gained from developing vacuum deposition equipment into the specifications for pressure resistance, airtightness, and leak testing, and I reviewed the welding structure in consultation with the manufacturer. Additionally, I revised the system and included it in the specifications. At that time, I was too busy to compile everything into systematic documentation. Thus, after becoming independent, I summarized my design technology for the carbon heater heating system.
Inquire About This Product
basic information
Overview of Design Technology for Carbon Heater Heating Systems The design will vary based on specific cases (purposes, applications, sizes, etc.) from item 5 onwards. 1. Design of main components such as the heating furnace casing, welding design, and inspection methods 2. Waterway design 3. Simple thermal calculations (design of power capacity, insulation materials, cooling water volume, etc.) 4. Design of the resistance value of the carbon heater 5. Electrode design 6. Design of the cooling water system 7. Design of the air supply and exhaust systems 8. Operating mode design 9. Design guidelines for flow within the furnace (considering product quality) 10. Temperature control and temperature distribution measurement methods Main Specifications of the Carbon Heater Heating Furnace (1) Maximum temperature: 2,500℃ (2) Heater: Insulation material: Carbon heater / Carbon-based molded insulation material (3) Furnace body structure: Water-cooled jacket (4) Furnace body material: Stainless steel (5) Temperature control: Radiation thermometer (control range 1,700℃ - 2,500℃) (6) Heating atmosphere: Reduced pressure / Inert gas (7) Vacuum exhaust: Below 10^(-2) (ultra-high vacuum is not included) (8) Gas supply system, vacuum exhaust system, cooling water system: Based on required functions and furnace body design. (9) Operating modes: Standby, heating up, operation, vacuum drawing, etc. Based on requirements.
Price information
Contents of the Technical Advisor Contract 1. Explanation of the Issues at Hand We will exchange opinions on what activities would be effective and efficient for the consulting company. 2. Finalizing the Contract Details (1) Theme of the Activities (2) Activity Details (number of visits, materials to be submitted, etc.) (3) Contract Duration (4) Determining the Contract Amount and concluding the contract. 3. Implementation of the Contract 4. Service Pricing For a contract duration of 6 months or more: 1 visit/month: 280,000 yen/month (Travel and accommodation expenses separate) For less than 6 months, consultation will be done individually.
Price range
P3
Delivery Time
Applications/Examples of results
【1】Applications that require heating to around 2,000℃ include: 1) Fiber optic drawing furnaces 2) Manufacturing equipment for carbon fibers 3) Melting furnaces and crystal growth furnaces for SiC and GaN 4) Melting and sintering furnaces for ceramics and others. 【2】Atmospheric furnaces above 1,000℃ A) Glassification furnaces for fiber optics (atmospheric pressure, halogen atmosphere) B) Thermal CVD furnaces (film formation of Si and GaN, atmospheric pressure/vacuum, hydrogen atmosphere + toxic gases) and others.
