Method for predicting the temperature of workpieces heated by a heating furnace and provision of an EXCEL tool.
The process of applying varnish or adhesive to tapes and substrates and then drying them is used in various industries. When the applied material is diluted with a solvent, the drying process that evaporates the solvent is crucial for quality control. If we try to increase productivity, the drying oven becomes larger, leading to higher equipment costs. Depending on the product, this also affects the subsequent curing process. To achieve efficient drying, the thermal performance of the heating furnace is necessary. It is very important for tape substrates that the thermal performance of the heating furnace remains stable within the range of use. The thermal performance of the heating furnace referred to here means the heat transfer rate. If the heat transfer rate and the temperature distribution of the heating furnace are known, the temperature of the substrate in the furnace can be predicted. Drying depends on the temperature of the substrate. Knowing the substrate temperature allows us to predict the evaporation rate or residual solvent. I serve as a technical advisor and possess the technology for measuring the thermal performance of furnaces. Additionally, I have the technology for thermal calculation methods that predict the substrate temperature based on thermal characteristics and temperature distribution within the furnace. By modeling the drying phenomenon of the applied material, we can predict the residual solvent.
Inquire About This Product
basic information
Once you enter into a technical advisor contract with us, we will provide the following technologies and information. We will support you until you can actually use it in your desired company. 1. Provision of technical information regarding the measurement methods and measuring tools for the heat transfer rate of heating furnaces. We will assist and advise on the fabrication of the tools. The design of the tools is crucial for accurate measurements. 2. Provision of methods for calculating the heat transfer rate from measurement data and advice on improving measuring tools. We will review the measurement results and make improvements to the tools. It may also be necessary to change the conditions of the heating furnace. 3. Provision of technical information on how to calculate the substrate temperature from the heat transfer rate and furnace temperature. It will be necessary to align the temperature from thermal characteristics with the measured temperature. 4. Creation of a drying model and development of the drying model calculation method. Since this involves model development, we will consult with you individually. 5. Resolution of issues in the drying process. Ultimately, our goal is to solve the challenges you currently face, and we will utilize thermal calculations for this purpose. Through the introduction of these technologies, we aim to achieve improvements and reforms in the drying process.
Price information
1. Explanation of the issues at hand We will exchange opinions on what themes would be effective and efficient for the companies that have consulted with us. 2. Finalizing the contract details (1) Theme of activity (2) Activity details (number of visits, materials to be submitted, etc.) (3) Contract duration (4) Determine the contract amount and conclude the contract. 3. Implementation of the contract 4. Service pricing For contracts of 6 months or more: 1 visit/month: 280,000 yen/month (Travel and accommodation expenses are separate) For less than 6 months, consultation will be done individually.
Price range
P3
Delivery Time
Applications/Examples of results
This thermal calculation method was utilized for the cooling of optical fibers and electrical wires. The development of the solvent for the coating material was carried out for the coating process of wire materials that use solvents. At that time, we also considered modeling the curing after drying. However, we did not reach the validation of the evaporation and curing models. After becoming independent, I conducted my own research and gathered information on modeling by investigating the evaporation and curing models. The models change depending on the coating material, and I would be very pleased if I could collaborate with the representatives of your company to develop the evaporation and curing models. I think this explanation may not be very clear, so please feel free to contact me.
Company information
The D&T Lab focuses on supporting research, development, design, and prototyping for manufacturing process design and production technology development. Particularly in the case of new businesses, it is necessary to introduce technologies that the company does not possess and to select and collaborate with partner companies. By utilizing so-called open innovation, we aim to shorten the marketing and product/service development periods, facilitate early entry into new fields and applications, and establish a unique strategy using that information and technology to actively promote the business. Once we reach that stage, operations can be managed similarly to existing businesses. Therefore, the challenge of new business ventures depends on how efficiently and effectively we design the entry phase. At that stage, it is essential to gather information and technologies that the company does not possess and to make suitable choices for the company. I have experience in the development and launch of mass production equipment and the introduction of new products into factories. From the successes and failures I encountered, I have learned how to design mass production lines and introduce new products in my own way. Additionally, I possess processing techniques for various materials such as copper products, compound semiconductors, quartz glass, and plastics. I will contribute using my knowledge of these mass production technologies and material processing techniques.
