We have prepared nearly 3,000 high-purity 2D mechanical parts. They can be quickly searched and placed on AutoCAD LT from a dedicated program.
An essential element in mechanical design is the component symbols. AutoCAD LT is widely used by many users in mechanical design, and its usability is enhanced by the ability to quickly place desired components through a structured, dedicated interface. It covers most of the necessary JIS mechanical parts, so please try the trial version once. Compatible with AutoCAD LT 2018 and 2019. The trial version is available on our website: http://uni-media.jp/jisparts.html
Inquire About This Product
basic information
Installed Component Types: Screws (9 types) / Gas pipes (1 type) / Taps (2 types) / Nuts (6 types) / Motors (2 types) / Symbols (6 types) / Fittings (16 types) / Hole drilling (3 types) / Steel materials (8 types) / Washers (2 types) / Shafts (7 types) / Vacuum piping (2 types) / Vacuum flanges (2 types) / Bearing units (11 types) / Bearings (24 types)
Price information
23,000 (including tax 24,860)
Price range
P2
Delivery Time
Applications/Examples of results
Released in April 2019
Company information
We have extensive experience in CAD customization and software development for the manufacturing and construction industries. We also have a significant track record in customizing BIM software such as Revit and creating families.
