This is a manual dry spraying device that disperses particles due to charging and achieves uniform distribution onto the work using an original fixed nozzle.
The tabletop spacer dispensing device "Model: XDS-Mini" is a manual tabletop spacer dispensing device. The dry spacer, weighed using an electronic balance, is transferred to the ejector table, and by manually moving the ejector, the spacer is suctioned and quantitatively dispensed onto the glass substrate placed in the chamber.
Inquire About This Product
basic information
【Dispersion Procedure】 1. Place the measured spacer on the dispersion platform using an electronic balance, and manually lift it into the dispersion piping. 2. The spacer becomes charged and dispersed due to friction with the dispersion piping. 3. Before being dispersed into the chamber, it is distributed onto the workpiece by N2 ejected in all directions from the multiplex nozzle. 4. By applying high voltage inside the dispersion chamber using an optional high-voltage power supply unit, the efficiency and distribution of the spacer are improved, and the adhesion of the spacer to the chamber walls is reduced. 【Specifications】 〇 Utilities: 1. N2 500L/min (temporarily used only during dispersion) 2. Exhaust φ50 3. Power supply AC100V (when using optional high-voltage power supply) 〇 Reference Size: 1. Chamber size H850mm x W500mm x D550mm 2. Workpiece size 150mm x 150mm ~ ● For more details, please contact us or download the catalog.
Price range
Delivery Time
Applications/Examples of results
For more details, please contact us or download the catalog.
Company information
Since our establishment in 1972, we have supported engineers and researchers involved in displays. We manufacture and sell various glass substrates and world-standard EHC cells both domestically and internationally, which are the core of our business. In recent years, there has been a growing demand for diverse metal deposition substrates and high-definition patterned glass substrates. As peripheral equipment, we provide custom small LCD panel assembly systems and wet process equipment, as well as dedicated systems for measuring and inspecting organic EL and organic solar cells, including simple jigs and more.
