Desktop inspection equipment for the inspection and maintenance of devices/circuit boards/equipment/apparatus.
This is a testing device that achieves high versatility and operability through modularized measuring instruments that can freely combine necessary functions and dedicated PC software that allows for programming of inspection procedures. It supports in-circuit testing and board testing. 【SYSTEM 8】 By combining the following measurement modules with distinctive functions, you can build an optimal test system for the necessary inspections. ○ Each module and its main functions ・Matrix Scanner (AMS)… V/I characteristic testing ・Board Fault Locator (BFL)… Fault diagnosis ・Test Module (ATM)… Digital IC testing ・Analog IC Tester (AICT)… Analog IC function testing ・Multi-Measurement Instrument (MIS4)… Versatile measurement functions ・Variable Power Supply (PPS)… Variable power supply for testing 【SYSTEM8 BoardMaster 8000 Plus】 This is an integrated general-purpose test system that incorporates all modules of the SYSTEM8 series along with a PC and monitor in a desktop-sized case. It is capable of digital and analog function testing, various V/I tests, fault diagnosis, and more.
Inquire About This Product
basic information
【Lineup and Features】 ◆ABI System 8 AMS - Frequency sweep V/I characteristic analysis - V/I characteristic analysis (static frequency) - Matrix V/I testing (multiple references) - Dynamic V/T testing (pulse output) - 64 channels/modules (expandable up to 2048 channels) BFL - In-circuit and board diagnostics (TTL/CMOS) - Truth table testing using circuit input/output libraries - Custom logic testing ATM - Connection, voltage, temperature, V/I testing - Diagnostics for all logic families, digital ICs, and boards - Testing with power on/off - Fault detection through functionality, voltage, connection, thermal, and VI testing AICT - Analog IC functionality testing - Connection and voltage testing - Graph analysis (VI) - Matrix V/I testing - VT testing MIS4 - Digital oscilloscope - Multimeter - Signal generator - Universal counter - Universal I/O - Data logging function PPS - Overvoltage protection - Overcurrent limitation ● For more details, please contact us.
Price information
Please contact us.
Delivery Time
Applications/Examples of results
○ Inspection of I/V characteristics of components ○ Inspection of the mounted circuit board
