Achieving ultra-slim and wide high-insulation windows! These windows allow you to feel the changes in nature.
The "WIDENESS WINDOW" is an insulated window that achieves a slim and large opening, creating a pleasant space. By opening the window, it plays an important role in integrating the room, window, and garden. It features a hybrid structure using cutting-edge insulation materials. It modernizes the unique engawa (veranda) of traditional Japanese houses, creating a space where light and breeze can be felt. 【Features】 ○ The visible dimension of the meeting frame is set to 38mm. ○ Both the outer frame and the sliding door use aluminum insulated materials. → Fiberglass-reinforced polyamide resin. ○ The maximum dimensions of the sliding door are W=1500mm, H=2700mm. ○ It uses heavy-duty rollers, allowing a sliding door weight capacity of up to 120kgf (recommended value). ○ The sliding types include double sliding and single sliding, with the possibility of multiple sliding doors. For more details, please contact us or download the catalog.
Inquire About This Product
basic information
【Product Variations】 ○ Sliding window ○ Multi-panel sliding window (6 panels) ○ Single sliding window 【Performance】 ○ Wind pressure resistance (Pa): S-5 (2400) ○ Air tightness (grade line): A-4 (A-4) ○ Water tightness (Pa): W-4 (350) ○ Thermal insulation (m²·k/W): H-4 (0.344) ○ Sound insulation (grade line): T-2 (30) 【Manufacturing Range】 ○ Frame width dimensions (mm) → Sliding window: W=1500–3600 → Multi-panel sliding window: W=4500–10800 → Single sliding window: W=1200–4000 ○ Frame height dimensions (mm): H=500–2700 ○ Shutter width dimensions (mm) → Sliding window: W=759–1809 → Multi-panel sliding window: W=750–1800 → Single sliding window: W=600–1800 ○ Shutter height dimensions (mm): H=518–2718 ○ Shutter width/height ratio (w/h): 0.4 ○ Maximum shutter area (m²): 4.0 ○ Maximum shutter weight (kg): 150 (recommended value considering operability: 120) ● For more details, please contact us or download the catalog.
Price information
Please contact us.
Delivery Time
※Please contact us.
Applications/Examples of results
For more details, please contact us or download the catalog.
