Silent due to contactless rotation! Dual-stable rotary solenoid with a reciprocating spring retention type.
The "SLF series" is a bistable rotary solenoid with a reciprocating spring retention type. The SC silent solenoid manufactured and sold by Esclaf is an actuator that utilizes the magnetic force generated by energizing the coil, designed to eliminate noise during operation. It features a structure developed from the principle of reluctance-type pulse motors, with a design that has no contact points other than bearings, making it silent. Leveraging these characteristics, it has numerous applications ranging from industrial equipment where noise is a concern to precision machinery. It achieves a long lifespan of several million to tens of millions of operations and is recognized for its reliability in automation lines where failures are unacceptable. **Features of the Rotary Solenoid:** - Can control rotation speed - Designed without axial stroke, making it easy to design - Can set rotation angles arbitrarily without burning out - Maximum torque is obtained at startup - Simple structure and long lifespan For more details, please contact us or download the catalog.
Inquire About This Product
basic information
【Specifications】 [SL60F-06/12-012] ○Rotation direction: Main operation CCW / Return operation CW ○Rated voltage DC: Main operation 6V / Return operation 12V ○Resistance at 20°C: Main operation 7.5Ω / Return operation 38.0Ω ○Rated current: Main operation 0.8A / Return operation 0.32A ○Operating angle: 45 degrees ○Rotor moment of inertia: 7.8×10^-6 kg·m² ○Weight: 1.1kg [SL60F-06/06-032] ○Rotation direction: Main operation CCW / Return operation CW ○Rated voltage DC: 6V ○Resistance at 20°C: 4.4Ω ○Rated current: 1.37A ○Operating angle: 45 degrees ○Rotor moment of inertia: 10×10^-6 kg·m² ○Weight: 2.0kg ●For more details, please contact us or download the catalog.
Price information
Please contact us.
Delivery Time
※Please contact us.
Applications/Examples of results
【Equipment and Applications】 ○Medical Devices →X-ray shutter opening and closing, laser shutter opening and closing ○Disaster Prevention Equipment →Damper opening and closing, shutter opening and closing, alarm buzzer ○Optical Equipment →Filter opening and closing, laser shutter opening and closing ○Textile Machinery →Thread tension, thread cutter, speed control ○Conveyors →Point switching (gate opening and closing) ○Office Equipment →Paper cutter drive unit, paper feeding, hole punching ○Food Equipment →Hopper opening and closing, weight sorting machine ○Measuring Instruments →Hopper opening and closing ○Gaming Equipment →Pachinko ball launching device, internal game mechanism, coin hopper ○Automatic Door Peripheral Equipment →Electronic lock for automatic doors ○Semiconductor-related Equipment →Coils for valves, control use ●For more details, please contact us or download the catalog.
