High-performance ultrasonic flaw detector with excellent versatility, equipped with a Blanview LCD display that offers outstanding visibility even in sunlight.
The DFX-8 series is a high-performance ultrasonic flaw detector that can be used for a wide range of applications, from flaw detection in welds to measuring high-damping materials such as castings and FRP, as well as thick materials. It is equipped with all the necessary functions for ultrasonic testing, including DAC (Distance Amplitude Correction), TCG, DGS/AVG, and curvature correction features. With a robust aluminum body, dust and drip-proof design (compliant with IP65), and a Blanview LCD display that ensures excellent visibility even in sunlight, it can be safely used outdoors. The higher model, DFX-8+, includes a 400V tone burst, narrowband filters at 0.5MHz and 15MHz, an interface gate for immersion testing, and external control and data output functions for automatic inspection on the production line. ■ Features - Blanview display that is easy to read outdoors - An astonishing measurement range of approximately 30m (equivalent to steel) - High-resolution measurement mode with a display accuracy of 0.001mm, ensuring high precision - All functions of the top model ultrasonic thickness gauge "CMX DL+" are standard - Supports operation with batteries, AC power, and dry batteries *For more details, please refer to the PDF document or contact us.
Inquire About This Product
basic information
■Specifications - Measurement range: 0 to 30,000mm (in steel) - Sound speed range: 256 to 16,000 m/s - Detection modes: Single transducer, dual transducer - Pulse repetition frequency: 8 to 2,000 Hz - Pulse voltage: 100, 150, 200 V - Pulse width: 40 ns, 80 ns, 400 ns - Linearity: Time axis FSW ±0.4%, Amplitude FSH ±1%, Amplifier accuracy ±1 dB - Measurement items: Beam path length, thickness, depth, distance, amplitude - Echo display: Full wave, positive half wave, negative half wave, RF - Detection: J-Frank, Frank, Peak, Zero-cross - Unit: mm (Standard mode: 0.01 mm, High-resolution mode: 0.001 mm) - Functions: DAC, TCG, AVG/DGS, AWS, Curvature correction function, Thickness gauge mode - Probe connector: LEMO 00 (small Lemo) × 2 - External interface: USB, LEMO 5-pin - IP rating: IP65 (dustproof and drip-proof) - Power supply: AC 100 to 240 V, Lithium-ion battery, 6 AA batteries - Dimensions: 216 (W) × 165 (H) × 70 (D) mm - Weight: Approximately 2 kg *For more details, please refer to the PDF document or contact us.*
Price range
P4
Delivery Time
P4
Applications/Examples of results
■Detection of internal defects in materials ■Detection of surface defects such as cracks ■Adhesion and peeling inspection ■Thickness measurement
Line up（2）
| Model number | overview |
|---|---|
| DFX-8 | ・Pulse voltage: 100, 150, 200V ・Filter: Wideband 1.8MHz～19MHz, Narrowband 1, 2, 5, 10MHz |
| DFX-8+ | ・Pulse voltage: 100, 150, 200, 400V ・Filter: Wideband 1.8MHz～19MHz, Narrowband 0.5, 1, 2, 5, 10, 15MHz ・Others: External control, voltage output, interface gate |
