Label dispenser
This is an automatic label peeling machine for roll labels with a maximum width of 178mm. It is compatible with roll labels from various label manufacturers and supports a variety of substrates (white PET, transparent PET, Neema, cast-coated paper, fine paper, kraft paper, foil paper, washi paper, Yupo, synthetic paper, etc.). It can accommodate free shapes such as squares, circles, stars, and multiple rows of labels. Labeling tasks can be performed efficiently with one hand. It is a fast type with a transport speed of 160mm/second. The maximum diameter of the label set bar (shaft) is 1 inch (approximately 25mm), and the maximum diameter of the included reel (a device that clamps the roll label from both sides) is 3 inches (approximately 76mm). As long as the inner diameter of the roll label core is 1 inch or more, it can be set on the label set bar. After setting the roll label, the sensor position and the pressure brush are adjusted using a butterfly screw. When the user takes the label that has been peeled off from the front, the next label is sent out and peeled off. (The user performs a motion to pinch the label upwards.) This is a simple and user-friendly electric label dispenser that is easy for beginners to use. The waste release paper is automatically wound up, maintaining a clean workspace.
Inquire About This Product
basic information
■Main Features ●Automatic transport and peeling ●Photo sensor ●Pressure brush ●Liner winding mechanism after peeling ●Power supply: AC100V ●Compatible with roll label core inner diameters of 1 inch or more ●Maximum diameter of label set bar: 1 inch (25mm) ●Maximum diameter of attached reel: 3 inches (76mm) ●If the core inner diameter is different from the above, set the label set bar without attaching the reel and use it.
Price range
Delivery Time
Applications/Examples of results
Label dispenser
